Wireless Ultrasound Probe Handheld Ultrasound Device With Scanning Depth 40-100mm Linear 90-200mm Convex

We are a medical ultrasound company engaged in R&D , production, sale and after-sales service.

We persistently cooperated closely with domestic and international famous medical ultrasound R&D organization

and keep in contact with related university ,labs professors and doctors to update latest data of ultrasound machines ,

also professional clinical applications experience.

W3 Ultrasound Scanners are wireless and working with a mobile app that is compatible with most iOS and Android smart devices

as well Windows system. Imaging transmission is done by internal 5G wifi , no external networks needed and work for most specialties

in hospitals , clinics, healthcare center etc.

Advantage

​Unlimited users, Free software, No hidden fees, Support printing reports,

Multi-languages: Chinese English Russian Italian Spanish Portuguese

Specification

Item	1	2	3
Type	Convex	Linear	Linear
Frequency	3.5-5MHz	7.5-10MHz	10-12MHz
Depth	90-200mm	40-100mm	20-50mm
Elements	128	128	128
Radius	R60	N/A	N/A
Length	N/A	45mm	28mm
Dimensions	160(h)*70(w)*30(d)mm	157(h)*70(w)*30(d)mm	157(h)*70(w)*30(d)mm
Package size	240(h)*235(w)*100(d)mm	240(h)*235(w)*100(d)mm	240(h)*235(w)*100(d)mm
Net weight	235g	217g	210g
Gross weight	1.1kgs	1.1kgs	1.1kgs
Wifi type	802.11g/20MHz/2.4G	802.11g/20MHz/2.4G	802.11g/20MHz/2.4G
Working system	Android,iOS,Windows	Android,iOS,Windows	Android,iOS,Windows
Software controls	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) Mode B,B/M Biopsy Page Left/Right Up/Down	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) Mode B,B/M Biopsy Page Left/Right Up/Down	GN(gain) 8TGC D(depth) ENH(enhancement) DR(dynamic range) F(frequency) Mode B,B/M Biopsy Page Left/Right Up/Down
Measurement	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) ​B+M: Heart Rate, Time, Distance	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) ​B+M: Heart Rate, Time, Distance	B: Length, Area/Circumference, Angle,Trace,Distance GA(CRL,BPD,GS,FL,HC,AC) EFW (BPD, FL) ​B+M: Heart Rate, Time, Distance
Applications	Abdominal, Emergency cardiac, Urology, Obstetrics, Gynecology,Lung, Kidney	MSK Breast Thyroid Superficial, Vascular Pediatrics Carotid, Small Parts	MSK Breast Thyroid Superficial, Vascular Pediatrics Carotid, Small Parts
Language	Chinese,English,Russian,Italian,Spanish,Portuguese(Brazil)	Chinese,English,Russian,Italian,Spanish,Portuguese(Brazil)	Chinese,English,Russian,Italian,Spanish,Portuguese(Brazil)
Battery life	5-8 years	5-8 years	5-8 years
Voltage	3.8v	3.8v	3.8v
Replaceable	Yes	Yes	Yes
Capacity	4200mAh	4200mAh	4200mAh
Standby	12h	12h	12h
Bootup	Platform dependent, generally <5 seconds	Platform dependent, generally <5 seconds	Platform dependent, generally <5 seconds

Standard Configuration
